The mountain bike experience starts here. With a redesigned frame thats now lighter and more durable, along with a smooth-riding suspension fork, thru-axle hubs*, and a 1x drivetrain*, this aluminum hardtail is everything an aspiring MTB rider needs to evolve and advance. *on select models
FEATURES:
- Modern MTB Design: Tapered fork steerer tubes*, quality components including a 1x drivetrain* with clutch-equipped rear derailleurs, thru-axle hubs*, internal cable routing (including dropper seatpost) and an integrated chainstay protector give aspiring trail riders room to grow. *on select models
- Off-Road Control: New geometry is optimized for confident trail riding and two different wheel sizes (27.5 or 29-inch) depending on frame size. The geometry is also designed for front suspension with either an 80mm or 100mm fork depending on frame size. All models have clearance for high-volume tires (up to 2.4-inch) for traction and grip on technical terrain.
- Light and Durable: All-new ALUXX aluminum frame features updated shaping and a lighter overall weight for improved performance on off-road terrain.
SPECS:
| Frame |
ALUXX-grade aluminum, disc |
| Fork |
SXC32-3 RL, coil spring, thru axle, steel steerer, 15×110 XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M:100mm travel (29) L: 100mm travel (29) XL: 100mm travel (29) XXL: 100mm travel (29) |
| Rear Shock |
N/A |
| Rims/Wheels |
Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width |
| Hubs |
[F] Giant Tracker hub, sealed bearing, 15×110 thru axle. [R] Giant Tracker hub, 12×142 thru axle, 24-pawl drive |
| Spokes |
stainless, 14g |
| Tires |
Maxxis Rekon 27.5×2.4″ or Maxxis Rekon Race 29×2.4″, wire bead |
| Crankset |
ProWheel Charm, 32t (27.5) or 30t (29) XS: 165mm (27.5) S: 165mm (27.5) / 170mm (29) M: 170mm (29) L: 170mm (29) XL: 175mm (29) XXL: 175mm (29) |
| Chainrings |
N/A |
| Bottom Bracket |
cartridge |
| Chain |
KMC X-11 |
| Front Derailleur |
N/A |
| Rear Derailleur |
Shimano CUES RD-U6000, clutch |
| Cassette/Rear Cogs |
Shimano CUES, CS-LG300, 11×48 |
| Shifters |
Shimano CUES SL-6000, 1×10 |
| Handlebars |
Giant Connect Trail, 31.8mm XS: 690mm (27.5) S: 690mm (27.5) / 750mm (29) M: 780mm (29) L: 780mm (29) XL: 780mm (29) XXL: 780mm (29) |
| Grips |
Giant Sole-O |
| Stem |
Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (29) L: 70mm (29) XL: 80mm (29) XXL: 90mm (29) |
| Brakes |
Tektro HDC M275, hydraulic, Tektro rotors [F]180mm, [R]160mm |
| Pedals |
MTB caged |
| Saddle |
Giant ErgoContact Trail |
| Seat Post |
Giant Contact Switch Core, 30.9 XS: 100x350mm (27.5) S: 100x350mm (27.5) / 100x350mm (29) M: 120x400mm (29) L: 120x400mm (29) XL: 120x400mm (29) XXL: 120x400mm (29) |
