PRODUCT DETAILS

FRAME SPECS:
Toptube Length: 20.5″
Chainstay Length: 14.3
BB Height: 11.45″
Headtube Angle: 74
Seattube Angle: 71

Recommended Rider Height: 5′ 4″ – 5′ 8″

FRAME: 6066 Aluminum Floval Tubing, Internally Machined Integrated Head Tube
HEADTUBE: Machined Integrated
BB SHELL: EURO
DROP OUTS: 3D-Forged Dropouts
BRAKE MOUNTING: V-Brake
SEAT CLAMP: 1 1/4″ aluminum
FORK: Full Cr-Mo Landing Gear, Tapered Legs
HANDLEBAR: Cr-Mo PK Bar, 28.5″ x 8.25″
STEM: SE Top-Load Alloy, Lightweight External Cutouts, Hidden Top Cap
GRIPS: SE Racing Wing Grip w/ SE Rubber End Plugs
HEADSET: Tange Sealed 1 1/8″ Integrated Headset
REAR BRAKE: Tektro BX-310 Alloy V-Brake
BRAKE LEVER: Tektro 316A, 2-Finger Alloy
BRAKE CABLE: Slick Cable
CRANKS: 175mm Forged Alloy 2-pc w/Hollow Axle
BOTTOM BRACKET: Integrated Sealed External BB
SPROCKET: Alloy 44T Chain Ring
PEDALS: X-Pedo Low-Profile Platform w/ Removable Pins
CHAIN: KMC Z33
HUBS: Sealed Bearing Hollow Axle Alloy Hubs, 16T Cassette
RIMS: Alex Supra BH20 32H F & DM22 36H R, Double Wall Rims
TIRES: Tioga Powerblock 1.95″ F, 1.60″ R
SPOKES: Stainless Spokes
SEAT: SE Sleek Seat With Custom-Imprinted Cover
SEAT POST: Race Rocker Micro-Adjust Aluminum, 27.2mm
MISC: Chain Tensioners, Race Plate

Weight: 21.40 lbs / 9.7 kgs

NOTE: As with any complete bike, J&R Bicycles recommends that you have a professional bicycle store build your bike. Bikes ordered through mail-order come partially assembled and need to be inspected and assembled by a bicycle mechanic. Failure to do so may void the manufacture’s warranty. Manufacture’s warranties differ for every brand. You can check the brand’s website for warranty information.
