FEATURES

• 100% Cr-Mo frame with integrated head tube, Mid BB shell, integrated seat clamp and removable brake and cable mounts 21″ top tube
• 100% Cr-Mo fork with internal threaded steer tube and tapered legs
• 100% Cr-Mo 9.25″ bars with Premium top load stem.
• Premium flangeless Team Grips.
• Three-piece Cr-Mo 175mm 8-spline cranks with sealed Mid BB.
• 28/9 gearing with alloy sprocket.
• Fully sealed wheels with front and rear double-wall rims and free-coaster rear hub.
• Premium CK tires 2.4″ front and rear.
• Premium Fat Capitol Pivotal seat with alloy Pivotal post.
• Premium Kinetic plastic pedals.

SPECIFICATIONS

• FRAME: 100% Full Cr-Mo, Integrated Headtube, MID BB, Removable Brake Mounts
• FORK: 100% Cr-Mo, Internal Threaded Steer Tube, Tapered Legs, 28mm Offset
• COLORS: Copper Raw Fade
• CRANKS: 3pc Seamless Tubular Cr-Mo 8 Spline, 175mm
• BOTTOM BRACKET: Sealed MID 19mm BB
• SPROCKET: 6061 Alloy, 28t
• GEARING: 28/9
• PEDALS: Premium Kenetic, Loose Ball 9/16″
• CHAIN: KMC, Z410
• CASSETTE: Freecoaster
• TIRES: Premium CK 20×2.4″
• FRONT HUB: 36H, Alloy Shell Sealed Bearing, 3/8″Axle
• REAR HUB: 36H, Freecoaster, Alloy Shell Sealed Bearing, 14mm Axle
• AXLE: 3/8 Front / 14mm Rear
• RIMS: 36H, Double Wall
• BRAKE: Die Cast Alloy 990
• BRAKE LEVER: Alloy w/ Hinge Clamp
• GRIPS: Premium Team Flangless
• HANDLE BAR: 100% Cr-Mo 9.25″ Rise, 10* back – 3* Up
• STEM: Premium Top-Loader, 50mm Reach
• HEADSET: Integrated Sealed Bearing
• SEAT: Premium Padded Pivitol
• SEAT POST: Alloy Pivotal, 25.4mm
• SEAT POST CLAMP: Integrated

GEOMETRY & SIZING

TT Size: 21

1. Head Angle: 75
2. Seat Angle: 71.5
3. Top Tube: 21 (533 mm)
4. Seat Tube: 10.25 (260.35 mm)
5. Chainstay: 13.75 (349.25 mm)
6. BB Height: 11.5 (292.1 mm)
7. Stand Over: 21.5 (546.1 mm)
